  • Functions: Record | Photo Capture | Alarm | Video Call
  • Ideal For: Private Space
  • Low Illumination
  • Standard PoE
  • Access Control Functions
  • 24 Months Warranty

Specifications

  • Product Category

    • Device Type

    • Video Door Phone Kit

    • Device Functions

    • Photo Capture | Video Call | Alarm | Record

    • Ideal For

    • Private Space

    • Installation Type

    • Wall Mount

  • Manufacturer Details

    • Brand

    • Hikvision

    • Model Series

    • DS-KIS603-P(B)

    • Model Number

    • DS-KIS603-P(B)

  • Product Dimensions (Open)

    • Dimensions In CM (WxDxH)

    • 20.00 x 14.00 x 1.50

    • Dimensions In Inches (WxDxH)

    • 7.90 × 5.50 × 0.60

  • Features

    • Additional Features

    • Low Illumination IR Supplement Mode: 3 M, BLC and DNR Support, True WDR, Field of View: Horizontal: 129 Degree and Vertical: 75 Degree, Motion Detection

  • Functions

    • Operating Humidity

    • 10 Percent to 95 Percent

    • Operating Temperature

    • -10 Degree Celsius to 55 Degree Celsius

    • Alarm

    • Yes

    • Additional Functions

    • Access Control Functions, Stores Messages and Captured Pictures in the TF Card, Remote Unlocking via the Client Software or the Mobile Client, Views Live Videos of Door Stations and Linked Cameras, Supports Wireless Network

  • Physical Attributes

    • On-Device Control Type

    • Buttons

    • On-Device Controls

    • Single-button Operation

  • Smart Features

    • Storage Type & Capacity

    • Memory: 128 MB, Flash: 32 MB

    • OS Name & Version

    • Embedded Linux Operating System

    • RAM Configuration

    • 256 M

  • Camera Features

    • Camera Type

    • HD Camera

    • Number of Pixels (Effective)

    • 2 MP

    • Recording Features

    • Main Stream: 1920 × 1080 Pixel, 720p, Sub stream: 704 × 576 Pixel

    • Additional Camera Features

    • Standard PoE, Low Illumination, Tamper-proof, Configuration Remotely via Web, Reading Frequency: 13.56 MHz

  • Exposure Features

    • Minimum ISO Sensitivity

    • NA

  • Exposure Features

    • Minimum ISO Sensitivity

    • NA

  • Shutter Features

    • Shutter Speed

    • NA

  • Device Screen Specifications

    • Screen Size in CM

    • 17.78 cm

    • Screen Size in Inches

    • 7 Inches

    • Type

    • TFT Screen

    • Resolution

    • 1024 × 600 PIxel

    • Touch Type

    • Multi-Touch

    • Additional Screen Specifications

    • Colorful Capacitive Touch Screen

  • Sound

    • Speaker Type

    • Built-in Speakers

    • Microphone Type

    • Built-in

    • Microphone Features

    • Omnidirectional Microphone

    • Audio Channel Specifications

    • 8 Channel Alarm Inputs

    • Other Sound Features

    • Two-way Audio Communication, Noise Suppression and Echo Cancellation, Audio Compression Rate: 64 Kbps

  • Network Connectivity

    • WiFi Supported

    • Yes

    • WiFi Specifications

    • IEEE 802.11b/g/n

    • Network Protocols

    • TCP/IP, SIP, RTSP

    • WiFi Features

    • 2.4G Wi-Fi

  • Ports & Slots

    • External Card Supported

    • Mifare Card

    • Ethernet Supported

    • Yes

    • Ethernet Specifications

    • 1 x RJ-45 10/100 Mbps Ethernet

    • Other Ports & Slots

    • 1 x Debugging Port

  • Additional Features

    • Indicators

    • 2 x Indicators

  • Battery Details

    • Standard Battery Life

    • NA

  • Plug Details

    • Power Consumption

    • 10 Watts

    • Grounded

    • Yes

    • Maximum Operating Temperature

    • 55 Degree Celsius

  • Materials & Durability

    • IP Rating

    • IP65

  • Aesthetics

    • Brand Color

    • Black

    • Color

    • BLACK

  • In The Box

    • Generic Name

    • Home Safety & Security

    • Main Product

    • 1 x Video Door Phone Kit U

    • Accessories

    • RemoteControl

    • Documents

    • Warranty Card | User Manual

  • In The Box

    • Main product

    • 1 x Video Door Phone Kit U

    • Accessories

    • Not Applicable

    • Package Includes

    • 1xVideo Door Phone Kit

    • Generic Name

    • Home Safety & Security

  • Product Dimensions (Open)

    • Dimensions In Inches (WxDxH)

    • 5.51 x 7.87 x 0.59

    • Dimensions In CM (WxDxH)

    • 14.00 x 20.00 x 1.51

    • Product Weight

    • 1.5 Kg

  • Packaged Dimensions

    • Package Dimensions in Inches (W x D x H)

    • 00

    • Package Dimensions in cm (W x D x H)

    • 00

  • After Sales & Services

    • Warranty on Main Product

    • 24 Months

    • Warranty Type

    • Carry-In

    • Standard Warranty Includes

    • Manufacturing Defects

    • Standard Warranty Excludes

    • Physical Damage

    • Installation & Demo

    • Not Applicable

      • Installation & Demo applicable

      • No

    • Company Contact Information

      • Customer Support Number

      • +91-22-28469900

      • Customer Support Email

      • support@hikvision.com

      • Manufacturer/Importer/Marketer Name & Address

      • Manufacturer Name & Address: No.555 Qianmo Road, Binjiang District, Hangzhou 310051, China

      • Country of Manufacture

      • China

      • Country of Brand Origin

      • China

    • Croma Contact Information

      • Customer Care Contact Person

      • Grievance Officer

      • Registered Name and Address

      • Infiniti Retail Ltd. - Unit No. 701 & 702, 7th Floor, Kaledonia, Sahar Road, Andheri (East); Mumbai - 400069. India

      • Customer Support Number

      • 1800 572 7662

      • Customer Support Email

      • customersupport@croma.com

    • Croma Service Promise

      • Customer Support Email

      • customersupport@croma.com

      • Registered Name and Address

      • Infiniti Retail Ltd. - Unit No. 701 & 702, 7th Floor, Kaledonia, Sahar Road, Andheri (East); Mumbai - 400069. India

      • Customer Support Number

      • 1800 572 7662

      • Customer Care Contact Person

      • Grievance Officer

    View More

    Overview

    Enhanced Video Capture

    You can experience high-quality video recordings with the HIKVISION 7-Inch Video Door Phone Kit's 2MP HD camera featuring true WDR technology. Thus, you can enjoy clear and detailed footage, even in challenging lighting conditions, ensuring you never miss any important details.


    Seamless Audio Communication

    Using the built-in omnidirectional microphone and loudspeaker, this video door phone kit lets you stay connected with visitors at your door. Moreover, you can enjoy crisp and concise audio recordings, enabling seamless two-way communication for enhanced security and convenience.


    User-Friendly Operation

    With the intuitive interface and remote configuration capabilities, this video door phone kit lets you navigate and configure the system effortlessly. So, whether adjusting settings or managing access controls, operating it is simple and hassle-free, offering convenience at your fingertips.


    Enhanced Security Features

    Thanks to the enhanced access control capabilities and a 7-inch colour touch screen, this video door phone kit empowers you to monitor and manage your property's security effectively. Furthermore, you can seamlessly integrate with other security tools such as door locks to create a comprehensive security solution.


    Versatile Applications

    Ideal for private spaces and areas with low illumination, this Hikvision video door phone kit offers versatile applications, ensuring optimal performance in various environments. Plus, with standard PoE support, it provides flexible installation options to suit your needs.


    Robust and Compact Design

    Designed to withstand the elements, this video door phone kit boasts an IP65 rating, ensuring effective service even in outdoor environments. Plus, its compact and sleek design adds a modern touch to your property while providing reliable security features.
